52
Chapter 4
Tool
This page includes the basic configuration tools, such as Configuration Tools (save or restore configuration settings),
Firmware Upgrade (upgrade system firmware) and Reset.
Parameters Description
4.1 Configuration Tools
You can save the router ’s current configuration, restore the router’s saved configuration
files and restore the router ’s factory default settings
4.2 Firmware Upgrade This page allows you to upgrade the router ’s firmware
4.3 Reset You can reset the router ’s system should any problem exist
Select one of the above three Tools Settings selection and proceed to the manual
’s relevant sub-section
4.1 Configuration Tools
The Configuration Tools screen allows you to save (Backup) the router ’s current configuration setting. Saving the
configuration settings provides an added protection and convenience should problems occur with the router and you
have to reset to factory default. When you save the configuration setting (Backup) you can re-load the saved
configuration into the router through the Restore selection. If extreme problems occur you can use the Restore to
Factory Defaults selection, this will set all configurations to its original default settings (e.g. when you first purchased the
router).
Parameters Description
Configuration Tools
Use the "Backup" tool to save the Broadband router current configuration to a file named
"config.bin" on your PC. You can then use the "Restore" tool to restore the saved
configuration to the Broadband router. Alternatively, you can use the "Restore to
Factory Defaults" tool to force the Broadband router to perform a power reset and
restore the original factory settings.
