Edimax Technology Broadband Router User Manual
Page 47
46
Parameters
Description
Tool
You can format your USB disk by this tool. This NAS router supports
FAT16, FAT32 and
EXT2.
Add
By clicking this button, you can launch the Add Partition page for you to add a new partition
on the USB disk.
Remove Partition
Select the partitions and click the
“Remove Select” to remove partitions or click “Remove
All
” to remove all partitions.
You can now configure other advance sections or start using the router (with the advance settings in place)
NOTE: The partition size with FAT16 file system should be less than 2GB, and for FAT32 or EXT2 file system, the
partition should be less than 160GB.
Auto Partition & Formatting
This function partitions and formats the USB storage disk in USB1 port according to the following rules.
(i) It partitions an USB storage disk in 160GB a partition and formats to
FAT32 file system.
(ii) If the rest of partition size is under 160GB, then it will be partitioned as
a partition.
(iii) This function only effects on the USB storage disk in USB1 port.
2.9.5 NAS Status
This Page shows the status of attached USB storage devices.
