19
by port number 8080, e.g. 10.0.0.1:8080 (see below). You ’ll also need to know the
password set in the Password Setting screen in order to access the router ’s web-
based management.
Port The port number of remote management web interface.
Enabled Select “Enabled” to enable the remote management function.
Click <Apply> at the bottom of the screen to save the above configurations. You can now configure other advance
sections or start using the router (with the advance settings in place)
2.2 WAN
Use the WAN Settings screen if you have already configured the Quick Setup Wizard section and you would like to
change your Internet connection type. The WAN Settings screen allows to specify the type of WAN port connect you
want to establish with your ISP. The WAN settings offer the following selections for the router
’s WAN port, Dynamic IP,
Static IP Address, PPPoE, PPTP, L2TP, Telstra Big Pond, DNS and DDNS.
Parameters Description
Dynamic IP Your ISP will automatically give you an IP address
Static IP Your ISP has given you an IP address already
PPPoE Your ISP requires PPPoE connection.
PPTP Your ISP requires you to use a Point-to-Point Tunneling Protocol (PPTP) connection.
L2TP Your ISP requires L2TP connection.
Telstra Big Pond Your ISP requires Telstra Big Pond connection.
DNS You can specify a DNS server that you wish to use
DDNS
You can specify a DDNS server that you wish to use and configure the user name and
password provided by you DDNS service provider.
Once you have made a selection, click <More Configuration> at the bottom of the screen and proceed to the manual
’s
relevant sub-section
