Extron Electronics RGB 103xi User Manual

Page 17

background image

6.95"

6.39"

0.6"

1.79"

1.79

” x 6.39

” OPENING IN DESK

RGB 103xi, RGB 109xi,
RGB 112xi Through
Desk Mounting
Bracket Template

.173" Dia. Bracket holes
(4 places)

TOP

Drill 3/32” x 1/4” deep
pilot holes for supplied
screws (4 places)

B-4
