RM

RGB 103/109/112

xi

xi

xi

xi

xi Specifications

LM

RGB 103/109/112

xi

xi

xi

xi

xi Specifications

Specifications, cont’d

A-3

Input impedance ......................... 10 kohms
Output impedance ...................... 75 ohms
Max. propagation delay ............. 48 nS
Max. rise/fall time ...................... 3.5 nS
Polarity .......................................... RGBHV: when RGBHV is input, polarity

follows input; otherwise negative
RGBS, RGsB: negative

Audio input

Number/type .............................. 1 PC level stereo, unbalanced
Connectors .................................... 1 3.5 mm stereo plug, 24” cable from

computer video connector, 2 channel;
tip (L), ring (R), sleeve (ground)

Impedance .................................... 10 kohms, DC coupled
Minimum level ............................ 100mV
Maximum level ............................ +8.5dBu,(unbalanced) @ stated %THD+N

Audio throughput

Gain ............................................... Unbalanced 0dB, balanced +6dB
Frequency response .................... ±0.05dB 20 Hz to 20 kHz
THD + Noise ................................ 0.03% @1 kHz, 0.3% @ 20 kHz at rated

maximum output drive

S/N ................................................ >90dB, output 14dBu, balanced
Stereo channel separation .......... >95dB @ 1 kHz to 20 kHz

Audio output

Number/type .............................. 1 stereo (2 channel), balanced/

unbalanced

Connectors .................................... 3.5 mm stereo captive screw terminal, 5

conductor, for left and right output

Impedance .................................... 50 ohms, unbalanced, 100 ohms balanced
Gain error ..................................... ±0.1dB channel to channel
Drive (600 ohm) ........................... > +14dBu, balanced at stated %THD+N

General

Power ............................................ 100VAC to 240VAC, 50/60 Hz, 15 Watts,

internal, auto-switchable

Temperature/humidity ............. Storage -40° to +158°F (-40° to +70°C) /

10% to 90%, non-condensing
Operating +32° to +104°F (0° to +40°C) /
10% to 90%, non-condensing

Rack mount .................................. No

A-2

Specifications

Specifications apply to all three units, except where noted.

Video input

Number/type .............................. 1 analog RGBHV, RGBS, RGsB, RsGsBs
Connectors .................................... RGB 103

xi: 1 15-pin D male, 48” long

cable
RGB 109

xi: 1 15-pin HD male, 48” long

cable
RGB 112

xi: 1 13W3 male, 48” long cable

Nominal level(s) .......................... Analog — 0.3V to 1.5V p-p
Maximum level(s) ....................... Analog — 1.5V p-p
Impedance .................................... 75 ohms
Horizontal frequency ................. Autoscan 15 kHz to 130 kHz
Vertical frequency ....................... Autoscan 30 Hz to 120 Hz
Return loss .................................... -30dB @ 5 MHz
Maximum DC offset ................... 4.0V

Video throughput

Gain ............................................... Unity, 0.725Vp-p with 50% peaking,

0.750V p-p with 100% peaking

Bandwidth .................................... 300 MHz (-3dB)

Video output

Number/type/format ................ 1 analog RGBHV, RGBS, RGsB
Connectors .................................... 6 BNC female

RGB 103

xi: 1 15-pin D female local

monitor output (buffered)
RGB 109

xi: 1 15-pin HD female local

monitor output (buffered)
RGB 112

xi: 1 13W3 female local monitor

output (buffered)

Nominal level .............................. Analog 0.70V p-p, 0.725V p-p, or 0.750V

p-p

Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz

Sync

Input type ..................................... RGBHV TTL (±), RGBS TTL (±), RGsB

0.3V (-), RsGsBs 1.3V (-)

Output type .................................. RGBHV (±), RGBS(±), RGsB (-)
Input level .................................... 2.0V to 5.5V p-p with ±0.2VDC offset

(max.)

Output level ................................. 4.0V to 5.0V p-p
