LM RGB 103/109/112 xi xi xi xi xi Reference Guide
Reference Guide, cont’d
RGB 103xi, RGB 109xi, RGB 112xi
Under Desk Mounting Bracket Template
Drill 3/32” x 1/4” deep
pilot holes for supplied
screws (4 places)
FRONT
7.06"
2.50"
B-2
Reference Guide
Part Numbers
Mounting brackets
Extron Part Part #
Under desk mounting bracket kit 70-077-01
Through desk mounting bracket kit 70-077-02
BNC cables
Extron Part Part #
BNC-5 HR cables
BNC 5-3’ HR
26-260-15
BNC 5-6’ HR 26-260-01
BNC 5-12’ HR 26-260-02
BNC 5-25’ HR 26-260-03
BNC 5-50’ HR 26-260-04
BNC 5-75’ HR 26-260-16
BNC 5-100’ HR 26-260-05
BNC-5 HR plenum rated cables
BNC-5-3’ HRP
26-378-01
BNC-5-6’ HRP 26-378-02
BNC 5-12’ HRP 26-378-03
BNC 5-25’ HRP 26-378-04
BNC 5-50’ HRP 26-378-05
BNC 5-75’ HRP 26-378-06
BNC 5-100’ HRP 26-378-07
Installation cables
Extron Part Part #
Bulk, 14-conductor, non-plenum 22-120-02
Bulk, 17-conductor, plenum 22-111-03
Audio connectors
Extron Part Part #
5-pole, 3.5-mm captive screw terminal 10-319-10
3.5-mm stereo plug 10-306-01
