30 GB
Introduction
LED Washbasin Fitting
Introduction
Congratulations on the purchase of your
new product. You have selected a high
quality product. The assembly and oper-
ating instructions are part of this product. Please
carefully read these assembly instructions / instruc-
tions for use before use and observe all instructions.
These assembly instructions and instructions for use
contains important assembly, set-up and care infor-
mation. Please retain these assembly instructions /
instructions for use and hand them on to any future
owner.
Intended use
The product is only designed to regulate the hot and
cold water flow. It is only intended to be installed in
washbasins. Suitable for use with all pressure-resist-
ant hot water systems such as central heating, con-
tinuous-flow water heater, pressure boiler etc. This
product is not suitable for low pressure water heat-
ers or pressure-free small storage reservoirs, e.g.
wood- or coal-burning domestic hot water heaters,
oil or gas-fired hot water heaters, or open electrically
heated cylinders. When in doubt please consult a
plumber or heating specialist. Any use not specified
or product modification is prohibited and will result
in damage. Any form of use other than the stipulated
intended purpose can cause danger to life and cause
injury. The product is for private use only and is not
intended for medical or commercial use. The manu-
facturer accepts no responsibility if the intended
purpose of this unit is not adhered to.
Parts description
1 Fitting
2 Fitting base seal
3 Pop-up pull rod (part 1)
4 Screw coupling between the two pull-rods*
5 Pop-up pull rod (part 2)
6 C sealing washer
7 C metal washer
8 2 Threaded bolts
9 2 Securing nuts*
10 2 flexible connecting hoses
11 Pop-up joint*
12 Pop-up knee-joint bar
13 Pop-up drain plug*
14 Pop-up seal (upper)*
15 Pop-up flange (upper)*
16 Pop-up seal (lower)*
17 Pop-up flange (lower)*
18 Pop-up screw thread*
19 Pop-up plastic nut*
20 2 Union nuts with seal*
21 Socket head wrench
22 LED installation spanner
23 Handle*
24 Locking screw*
25 Warm- / cold plaque*
26 Cartridge covering ring*
27 Cartridge locknut*
28 Cartridge*
* prefitted
Technical Data
Connections: G 3 / 8“
Service pressure: min. 1.5 bar – max. 10 bar
Flow at 3 bar: approx. 5.6 to 6.8 L / min,
varies by water temperature
LED light: approx. < 33°C blue,
approx. 33–43°C green,
approx. > 43°C red
approx. > 53°C flashing red
LED life: approx. 10,000 operating
hours
Temperature sensor
tolerance:
+/- 2°C
Scope of delivery
1 Washbasin fitting 1
1 Fastening kit ( 2 , 6 – 9 )
