INSTALLATION
The C82305* /C82306* interface card is designed to be
installed inside the printer. Installation or removal of the
interface board is easy, and requires only a screwdriver.
The following section gives you detailed information on
how to install your interface card in a variety of
EPSON printers.
Caution
• Turn off the power to the printer and the computer
before installing the serial interface. Make sure that all
power and interface cables are removed.
• Avoid touching the printer’s circuit board contacts, as
many of these components are sensitive to static
electric charges that may build up on your body.
1. First, you may need to adjust the DIP switches and
jumper settings.
If the screws don’t fit your interface cable, you will
need to replace the connector lock nuts with the
optional ones provided in this package.
Note
The original CS2305* lock nuts are imperial standard
(inch), and the C82306* lock nuts are metric.
22
