Note
• The printer will assume a setting of 1,200 BPS for
switch combinations other than those shown above.
• Since the maximum transmission speed (baud rate)
depends on your type of printer, refer to your
printer’s manual for details.
Jumpers
The jumper is a small terminal used for connecting or
disconnecting a circuit. The jumper is on when the
jumper plug covers both wires of the terminal. Jumper
settings can be changed by either attaching or removing
the rectangular jumper plug. If the jumper is to be
turned off, connect it to just one of the two terminal
pins as shown in the figure below. By doing this, you
can avoid losing the unused jumper plug.
Figure 2. Jumpers
10
