Crivit Floor Pump - Manual (Page 15)

15 GB
Inflating balls
Insert the ball adapter into the large opening (B)
of the dual pump head. Flip the clamping lever
(D) up to lock in the adapter. Then insert the
adapter in the ball.
Inflatables
Open the valve on the inflatable. Insert the
properly fitting inflatables adapter into the large
opening (B) of the dual pump head. Flip the
clamping lever (D) up to lock in the adapter.
Then insert the adapter into the valve of the
inflatable.
Inflating bicycle tyres with Dunlop
valves
Remove the closure from the bicycle tyre. Place
the small opening (C) of the dual pump head on
the valve. Flip the clamp lever (D) up to lock the
adapter.
Inflating bicycle tyres with Schrader
valve
Remove the closure from the bicycle tyre. Place
the large opening (B) of the dual pump head on
the valve. Flip the clamp lever (D) up to lock the
adapter.
Inflating bicycle tyres with Presta
valves
Remove the closure from the bicycle tyre. Loosen
the valve nut. Place the small opening (C) of the
dual pump head on the valve. Flip the clamp
lever (D) up to lock the adapter.
B
C
D
E
F
