COM Port Pinout Assignments
Specifications
A-3
A.2
COM PORT PINOUT ASSIGNMENTS
The COM port is a serial communications port that supports Local Management or connection to
a UPS.
shows the COM port pin assignments.
A.3
REGULATORY COMPLIANCE
The 6H302-48 and 6H303-48 modules meet the following safety and electromagnetic
compatibility (EMC) requirements:
Table A-2
COM Port Pin Assignments
Pin
Signal Name
Input/Output
1
Transmit Data (XMT)
Output
2
Data Carrier Detect (DCD)
Output
3
Data Set Ready (DSR)
Input
4
Receive Data (RCV)
Input
5
Signal Ground (GND)
NA
6
Data Terminal Ready (DTR)
Output
7
Request to Send (RTS)
Input
8
Clear to Send (CTS)
NA
Table A-3
Compliance Standards
Regulatory Compliance
Standards
Safety
UL 1950, CSA C22.2 No. 950, 73/23/EEC,
EN 60825, EN 60950, and IEC 950
Electromagnetic Compatibility (EMC)
FCC Part 15, CSA C108.8, 89/336/EEC, EN 55022,
EN 61000-3-2, EN 61000-3-3, EN 55024,
AS/NZS 3548, and VCCI V-3
