Specifications A-1
A
Specifications
This appendix provides operating specifications for the 6H302-48 and 6H303-48 modules.
Enterasys Networks reserves the right to change the specifications at any time without notice. If
not specified by module name, the statistics are the same for both modules.
A.1 6H302-48 / 6H303-48 SPECIFICATIONS
Table A-1 provides the processors and memory, physical properties, environmental module
specifications, and I/O ports for the 6H302-48 and 6H303-48 modules.
Table A-1 6H302-48 / 6H303-48 Specifications
Item Specification
Processors/Memory
Processors: Intel i960 HT RISC processor Power PC
Dynamic Random Access
Memory (DRAM):
20 MB
FLASH Memory: 8 MB expandable to 16 MB
Shared Memory: 4 MB
Physical Properties
Dimensions: 46.43 H x 6.05 W x 29.51 D (cm)
18.28 H x 2.38 W x 11.62 D (in)
Approximate Weight (Unit): 2.04 kg (4.5 lb)
MTBF (Predicted):
6H302-48
6H303-48
176,149 hours
183,945 hours
