Network Requirements
2-1
2
Network Requirements
Before installing the module, review the requirements and specifications referred to in this chapter
concerning the following:
•
SmartTrunk (
•
10BASE-T Twisted Pair Network (
)
•
100BASE-T Twisted Pair Network (
)
The network installation must meet the requirements to ensure satisfactory performance of this
equipment. Failure to do so will produce poor network performance.
2.1
SMARTTRUNK FEATURE
Before connecting the module to a network so it can take advantage of the SmartTrunk feature,
there are certain rules concerning port connections and configurations that must be followed for
proper operation. Refer to the appropriate Local Management User’s Guide for additional
information.
2.2
10BASE-T NETWORK
When connecting a 10BASE-T segment to any of the module ports (1 through 48), ensure that the
network meets the Ethernet network requirements of the IEEE 802.3 standard for 10BASE-T.
Refer to the Cabling Guide for details.
NOTE: The appropriate Local Management User’s Guide and Cabling Guide referred to
in the following sections can be found on the Enterasys Networks World Wide Web site:
NOTE: If a port is to operate at 100 Mbps, Category 5 cabling must be used.
Category 3 cabling does not meet 100 Mbps specifications. For 10 Mbps operation only,
Category 3 or Category 5 cabling can be used. Refer to
for information
about 100BASE-TX networks and cabling.
