ELECTRO-VOICE ® XLC TM Rigging Manual 8
Figure 4a:
XLC-127 and XLC-127+ Rigging Dimensions
Rear View
Side View
CL
Front View (With Grille)
Hole Detail
Scale = 3:1
5.63in
(143mm)
Typ.
8.75in
(222mm)
1.00in
(25.4mm)
Typ.
38.22in
(971mm)
Cent.
4.88in (124mm)
4.75in (121mm)
0.38in
(9.7mm) R4.94in (125mm)
1.22in
(31.0mm)
Typ.
37.53in
(953mm)
Cent.
0.65in
(16.5mm)
Typ. Dia .385in
(9.8mm)
(11 Plcs.)
.730in (18.5mm) Typ.
.365in (9.3mm)
.300in (7.6mm)
20.90in
(531mm)
.730in (18.5mm) Typ.
0° Hole
1° Hole
2° Hole
3° Hole
4° Hole
5° Hole
6° Hole
7° Hole
8° Hole
