ELECTRO-VOICE ® XLC TM Rigging Manual 20
Figure 8:
XLC-127, XLC-127+ and XLC-118 Front-Rigging-Point
Structural Ratings
0
100
200
300
400
500
600
700
800
900
1000
1100
-180 -150 -120 -90 -60 -30 0 30 60 90 120 150 180
Angle (Degrees)
W
o
rk
ing-
Load Li
m
it
(
lb)
0
50
100
150
200
250
300
350
400
450
500
W
o
rk
ing-
Load Li
m
it
(
k
g)
- ∅ °
+ ∅ °
- 5 °
MAX
+ 5 °
MAX
