ELECTRO-VOICE ® XLC TM Rigging Manual
3. Rigging-Strength Ratings, Safety Factors, and
Special Safety Considerations
3.1 Working-Load Limit and Safety Factor Definitions
The structural ratings for all of the XLC rigging components and complete loudspeaker systems
are based on test results in which parts were stressed to failure. Manufacturers typically present
the structural-strength ratings of mechanical components or systems as either the working-load
limit (WLL) or the ultimate-break strength. Electro-Voice chooses to present the structural-load
ratings of the XLC loudspeaker systems as the working-load limit. The working-load-limit rating
represents the maximum load that should ever be applied to a mechanical component or system.
THE USER SHOULD NEVER APPLY A LOAD THAT EXCEEDS THE WORKING-
LOAD LIMITS OF ANY OF THE RIGGING COMPONENTS OR COMPLETE
LOUDSPEAKER SYSTEMS DESCRIBED IN THIS MANUAL.
The working-load limits for the XLC rigging components and complete loudspeaker systems
described in this manual are based on an 8:1 safety factor. The safety factor is defined as the
ratio of the ultimate-break strength divided by the working-load limit, where the ultimate-break
strength represents the force at which a part will structurally fail. For example, if a part has
working-load limit of 1,000 lb (454 kg), it would not structurally fail until a force of at least 8,000 lb
(3,629 kg) was applied, based on a 8:1 safety factor. However, the user should never apply a load
to that part that exceeds 1,000 lb (454 kg). The safety factor provides a margin of safety above
the working-load limit to accommodate normal dynamic loading and normal wear.
CAUTIONS for Working-Load Limits and Safety Factors
The working-load limits defined by the manufacturer of any rigging component should never be
exceeded. Electro-Voice bases the working-load limits of its XLC products on an 8:1 safety factor.
Other manufacturers of rigging components may base their working-load limits on safety factors
other than 8:1. For example, 5:1 safety factors are fairly common amongst rigging manufacturers
because many regulatory agencies call for a minimum safety factor of 5:1.
When an XLC loudspeaker system is installed where local regulations only require a safety factor
of 5:1, Electro-Voice insists that the working-load limits of the XLC rigging never be exceeded and
that an 8:1 safety factor be maintained for the XLC loudspeakers.
The user is cautioned that some local regulations may require safety factors higher than 8:1. In
that circumstance, Electro-Voice insists that the user maintain the higher safety factor as required
by the local regulations throughout the entire XLC installation. It is the responsibility of the user to
make sure that any XLC installation meets any applicable local, state or federal safety regulations.
15
