Crivit CEB 1400 A1 - Manual (Page 53)

49 CEB 1400 A1
GB
Appendix
Technical Data
Power adapter GQ07-050060-AG
Input voltage 100 - 240 V ~ 50/60 Hz
Current consumption max. 0.3 A
Output voltage 5 V
Output current 600 mA
Protection class II /
Operating temperature +15 to +35°C
Humidity (no condensation) ≤ 75 %
Ni-MH Battery Pack
Voltage 3.6 V
Capacity 1400 mAh
Charging time approx. 6.5 - 8 hrs
Insoles
Input voltage 3.6 V
Current consumption 300 mA
Shoe sizes 36 - 48
Max. operating time
approx. 5 hrs
(at Heat Level II)
Information regarding the EC
Declaration of Conformity
In regard to compliance with basic requirements
and other relevent provisions, this appliance con-
forms with the Low Voltage Directive 2006/95/EC
and the Electromagnetic Compatibility Directive
2004/108/EC.
The complete original Declaration of Conformity
can be obtained from the importer.
