8 Golden Iridescence
TM
9. ASSEMBLYING AND ATTACHING
THE FAN BLADES
Fig. 17
Fig. 19
Fig. 18
10. INSTALLATING THE MOUNTING PLATE
Step 2. Make sure the blade is straight and
tighten each screw until the fiber washer is
slightly compressed and all three screws are
secure.
Step 3. Attach each completed blade assem-
mounting screws in each blade bracket. (Fig.
18) Make sure each mounting screw is
Step 1. Attach the blade to the blade
bracket using the screws, washers and
fiber washers provided. Refer to Fig. 17 as
needed. Start each screw into the bracket.
Repeat for the two (2) remaining screws.
1. Remove 1 of the 3 screws on the mount-
ing ring and loosen the other 2 screws. Do
2. Place the key holes on the mounting
plate over the 2 screws previously loos-
ened and turn the mounting plate until it
locks in place at the narrow section of the
key holes. Secure by tightening the 2
screws previously loosened and reinstall
the one removed. (Fig. 19)
Blade
Screws
Blade
Blade bracket
Mounting plate
Screw
Mounting ring
Screw
Metal washer
Fiber washer
Blade bracket
not remove the mounting ring located on
the motor shaft.
securely tightened.
bly to the face of the motor using the “pre-installed”
