Empire Comfort Systems BVD36FP32 - Manual (Page 28)

Page 28 19400-3-0406
USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
INDEX
NO.
PART NUMBER DESCRIPTION
BVD34L BVD34F BVD36L BVD36F
1 19506 19506 19507 19507 TOP SHIELD
2 17301 17301 17301 17301 TOP STANDOFF (2 REQUIRED)
3 10554 10554 10554 10554 NAILING FLANGE (4 REQUIRED)
4 M163 M163 M178 M178 FLUE OUTLET GASKET
5 19387 19387 19422 19422 FLUE OUTLET ASSEMBLY
6 19398 19398 19398 19398 DOWNDRAFT BAFFLE
7 19402 19402 19434 19434 DRAFT BAFFLE
8 R7052 R7052 R7052 R7052 SCREEN ROD
9 R8137 R8137 R8148 R8148 SCREEN
10 17127 N/A 18807 N/A UPPER LOUVER ASSEMBLY
11 17128 N/A 18808 N/A LOWER LOUVER ASSEMBLY
12 17162 17162 17162 17162 JUNCTION BOX ASSEMBLY (DIRECT IGNITION & LOUVERED
MODELS ONLY)
12a 17163 17163 17163 17163 JUNCTION BOX COVER PLATE
13 R3492 R3492 R3492 R3492 RECEPTACLE (DIRECT IGNITION & LOUVERED MODELS ONLY)
14 19435 19435 19436 19436 VALVE ACCESS DOOR
15 17235 17235 17235 17235 LOG LOCATOR BRACKET
16 R7580 R7580 R8020 R8020 BURNER TUBE
17 R5676 R5676 R5676 R5676 AIR SHUTTER
18 P252 P252 P286 P286 ORIFICE (NAT)
19 R7572 R7572 R7572 R7572 JAMB NUT
20 P212 P212 P212 P212 ORIFICE HOLDER
21a 19384 19384 19420 19420 TUBING ASSEMBLY
21b 19404 19404 19440 19440 TUBING ASSEMBLY
22 R2423 R2423 R2423 R2423 MALE ADAPTOR
23 R7590 R7590 R7590 R7590 SPARK IGNITOR (DIRECT IGNITION)
24 17315 17315 17315 17315 SPARK IGNITOR MOUNTING PLATE (DIRECT IGNITION)
25 R8132 R8132 R8132 R8132 PILOT (MILLIVOLT)
25a R5710 R5710 R5710 R5710 THERMOPILE
26 R7617 R7617 R7617 R7617 PILOT GASKET
27 19382 19382 19418 19418 BURNER BASE ASSEMBLY
28a 19381 19381 19381 19381 VALVE BRACKET (MILLIVOLT)
28b 19403 19403 19403 19403 VALVE BRACKET (DIRECT IGNITION)
29a R8380 R8380 R8380 R8380 VALVE, GAS (MILLIVOLT)
29b R7568 R7568 R7568 R7568 VALVE, DIRECT IGNITION (120V)
30 R2708 R2708 R2708 R2708 PIEZO IGNITOR (MILLIVOLT)
31 R7613 R7613 R7613 R7613 IGNITOR WIRE (SPARK PLUG WIRE) (DIRECT IGNITION)
32 R8143 R8143 R8143 R8143 CONTROL MODULE, ELECTRONIC (DIRECT IGNITION)
33 R8144 R8144 R8144 R8144 WIRE ASSEMBLY (DIRECT IGNITION)
34 R7615 R7615 R7615 R7615 CORD SET (DIRECT IGNITION)
35a R8133 R8133 R8133 R8133 WIRE ASSEMBLY, LIMIT SWITCH (MILLIVOLT)
35b R8147 R8147 R8147 R8147 WIRE ASSEMBLY, LIMIT SWITCH (DIRECT IGNITION)
36 R8145 R8145 R8145 R8145 WIRE ASSEMBLY, WALL SWITCH (ON/OFF)
37 R7587 R7587 R7556 R7556 REAR LOG
38 R7586 R7586 R7555 R7555 MIDDLE LOG
39 R7585 R7585 R7553 R7553 FRONT LEFT LOG
40 R-7588 R7588 R7557 R7557 "Y" BRANCH
41 R7554 R7554 R7554 R7554 FRONT RIGHT LOG
42 R7591 R7591 R7591 R7591 FLEX LINE/SHUTOFF VALVE
43 R8593 R8593 R8375 R8375 SWITCH, LIMIT
44 - - 19918 19918 BRICK PANEL, PAINTED
BVD34 & BVD36 PARTS LIST
