Platinum Spot LED™
©Elation Professional, Los Angeles Ca.
40
www.ElationLighting.com
96-127
No function (shutter open)
128-159
Pulse-effect in sequences
160-191
No function (shutter open)
192-223
Random strobe effect slow to fast
224-255
No function (shutter open)
Dimmer (intensity)
13
11
16
0-255
Intensity 0 to 100%
Iris
0-191
Maximum diameter to Minimum diameter
192-223
Pulse closing fast to slow
14
12
17
224-255
Pulse closing slow to fast
Iris Fine
18
0-255
Iris Fine
Speed pan/tilt movement
0-225
Max to min speed
226-235
Blackout with pan/tilt movement
236-245
Blackout with any motor movement
15
13
19
246-255
No function
Lamp on/off, reset, internal programs
0-19
Color / Gobo change normal
20-29
Color change to any position
30-39
Color / Gobo change to any position
40-59
No function
60-79
No function
80-84
All motor reset
85-87
Scan motor reset
88-90
Colors motor reset
91-93
Gobo motor reset
94-96
No function
97-99
Other motor reset
100-119
Internal program 1 (secne1~8 of EEPROM)
120-139
Internal program 2 (secne9~16 of EEPROM)
140-159
Internal program 3 (secne17~24 of EEPROM)
160-179
Internal program 4 (secne25~32 of EEPROM)
180-199
Internal program 5 (secne33~40 of EEPROM)
200-219
Internal program 6 (secne41~48 of EEPROM)
220-239
Internal program 7 (secne49~56 of EEPROM)
16
14
20
240-255
Music Control (scene of Program 1)
