seconds from the last command. In order to deactivate or temporarily deactivate the
key lock function, press the Mode/Esc Button for 3 seconds to regain access to the
menu commands.
8.3.4 Temperature C/F – This function changes the temperature the unit will display
from either Celsius or Fahrenheit. Fahrenheit is set as the default measurement.
8.3.5 Initial effect – This function allows a user to create and assign a custom “Home
Position” into the fixture. Adjusting the Pan and Tilt values then locking those values into
the fixture’s internal memory creates the new “Home” position.
8.3.6 Reset Default – This function is used to restore the factory settings of the device.
All settings will be set back to the default values (shaded). Any edited scenes will be lost.
8.4 Reset Functions: The reset function returns a motor to the “Home” position. There are
several reset functions available on this fixture. The list below details the functionality of
each available selection.
Ø
Reset All: This function will reset all internal motors to the home position.
Ø
Reset Pan and Tilt: This function will only reset the pan and tilt motors to the home
position.
Ø
Reset Colors: This function will only reset the color wheel to the home position.
Ø
Reset Gobos: This function will only reset the gobo wheels to the home position.
Ø
Reset Others: This function will reset all other motors not associated with any in the
previously listed reset commands to the home position.
8.5 Effect Adjust:
8.5.1 Test Channel – This menu function allows the user to select each individual
fixture channel and test it’s function independently from the control board.
8.5.2 Manual Control – Allows for manual control of all fixture functions for testing
purposes. This function will center the pan and tilt motors and at the same time open
the shutter and bring the dimmer to 100%. The pan and tilt function will still operate if
