Test Channel

PAN ……

Test function

Manual Control

PAN =XXX
:

Fine adjustment of the lamp

Calibrate Values Calibrate Password =XXX

Color wheel=XXX
:

Password “050”
Calibrate and adjust function
wheel to the proper home
position

User Mode

Standard Mode
Basic Mode
Extended Mode
User Mode A
User Mode B
User Mode C

Changes

DMX

channel

modes. Also stores user
defined channel mode sets.

Edit User Mode

Max Channel = XX
PAN = CH01
:

Preset User modes

Select Programs Auto Pro Part 1 = Program 1 ~ 10

Program 1
Auto Pro Part 2 = Program 1 ~ 10
Program 2
Auto Pro Part 3 = Program 1 ~ 10
Program 3

Select programs to be run

Edit Program

Program 1
:
Program 10

Program Test
Step 01=SCxxx
Step 64=SCxxx

Testing program
Program in loop
Save and exit

Edit Scenes

Edit Scene 001
~ Edit Scene 250

Pan,Tilt,……
--Fade Time--
--Secne Time--
Input By Outside

Save and automatically
return manual scenes edit

Rec. Controller

XX~XX

Automat. scenes rec

8.1 Function Mode:

8.1.1 “Set DMX Address” - DMX address setting – This function is used to set or

adjust the fixture’s starting DMX address. Every device controlled by DMX has to have a

unique starting address. The addressing feature is what allows DMX to function

properly. The DMX address of a fixture is what allows it to communicate with a controller

properly. The DMX addressing also allows the fixture to ignore any DMX information

coming from the controller that is not meant specifically for the fixture. Because each
