Controller Settings:
1. Set the DMX value of channel 1 to a value of 7.
2. Set the DMX value of channel 2 to a value of 7 or 8. When channel 2 is set to "7"
you can adjust the starting address between 1 and 255. When set to "8" you can
adjust the starting address between 256 and 511.
3. Use channel 3 to set your desired DMX starting address. For example: If you
want to set the starting address to 57, set channel 1 to a value of “7,” set channel
2 to a value of “7” and use channel 3 to set your address to 57 by selecting a
channel value of 57. Example 2: If you want to set the starting address to 420, set
channel 1 to a value of “7,” channel 2 to "8" and channel 3 to "164"
(256+164=420).
4. The above example assumes the fixture is addressed at 001, for any other
address follow the above instruction for the actual staring address in place of 1.
For example: If you want to set the starting address to 57, when the starting
address is set at 163. Set channel 163 to a value of “7,” set channel 164 to a
value of “7” and use channel 165 to set your address to 57 by selecting a channel
value of 57.
5. Wait for approximately 20 seconds for the unit to complete the address
reset function.
