Installation, Positioning the projector – Eiki LC-XB40N User Manual
Page 17

17
Positioning the Projector
Installation
100"
150"
200"
300"
247"
166"
124"
82"
33"
40"
A
B
32.8’ (10.0 m)
22.0’ (6.7 m)
16.4’ (5.0 m)
10.8’ (3.3 m)
Max. Zoom
Min. Zoom
A : B = 9 : 1
Screen Size
(W x H) mm
4 : 3 aspect ratio
Zoom (min)
40”
Zoom (max)
813 x 610
5.2’ (1.6m)
4.3’ (1.3m)
100”
2032 x 1524
13.1’ (4.0 m)
10.8’ (3.3 m)
150”
3048 x 2286
20.0’ (6.1 m)
16.4’ (5.0 m)
200”
4064 x 3048
26.6’ (8.1 m)
22.0’ (6.7 m)
300”
6096 x 4572
––––
32.8’ (10.0 m)
(Inch Diagonal)
4.3’ (1.3 m)
(Center)
For projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the
screen.
✔
Notes:
•The brightness in the room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain
the best image.
•All measurements are approximate and may vary from the actual sizes.
33”
671 x 503
4.3’ (1.3 m)
––––
