Part names and functions, Front, Back – Eiki LC-XB40N User Manual
Page 10: Bottom, Bottom back

10
Bottom
Back
q Zoom Ring
w Infrared Remote Receiver
e Focus Ring
r Projection Lens
t Slide Shutter Lever
y Top Controls and Indicators
u Exhaust Vent
i
!6
!3
!5
!4
!1
!2
CAUTION
Hot air is exhausted from the exhaust
vents. Do not put heat-sensitive objects
near this side.
u
e r
t
y
Front
Part Names and Functions
!7
!0
o
q
w
✔
Note:
• !2 USB Terminal and !3 LAN Connection
Terminal are for the Network function. Refer
to the owner’s manual “Network Set-up and
Operation” and owner’s manual of Memory
viewer (optionally available).
u
o
o
!6
i Speaker
o Air Intake Vents
!0 Terminals and Connectors
!1 Power Cord Connector
!2 USB Terminal
!3 LAN Connection Terminal
!4 Lamp Cover
!5 Air Filter
!6 Adjustable Feet
!7 Battery Cover
✽ Kensington Security Slot
This slot is for a Kensington lock used to deter
theft of the projector.
* Kensington is a registered trademark of ACCO Brands
Corporation.
✽
