Elation Professional LED 12 Brick II User Manual
Page 9
Design LED 12 Brick II ™
©Elation Professional, Los Angeles Ca.
8
www.ElationLighting.com
5. FIXTURE OVERVIEW
1
2
3
4
5
6
7
8
9
10
11 12 13 14
1. Bracket Locking Knob – This knob is used to secure the bracket in place after
angle adjustments have been made.
2. Diffusing
Lens
– This lens is used to both protect the LEDS as well as diffuse the
light output.
3. LED
Assembly
– RGB LED assembly 3x1watt LEDS
