Design LED 12 Brick II ™
©Elation Professional, Los Angeles Ca. 9 www.ElationLighting.com
4. On/Off Power Switch – Controls main power to the unit.
5. Power Output Jack – Use this jack to jump power to another Design LED 12 Brick II
™
6. Power Input/Fuse Holder Assembly – This assembly holds the safety fuse as well
as provides a female IEC connector for a power cord. Always replace the fuse with
an exact match unless otherwise specified by an authorized Elation Service
Technician. Using a fuse other than that specified could seriously damage the unit
and will void your manufactures warranty.
7. Eye-Bolt - Use this bold as a safety-cable rigging point. Always secure any installation
with a properly rated safety-cable.
8. LED MENU DISPLAY – Four segment LED menu display, details all menu functions
9. DMX In Jack – This jack accepts an incoming DMX signal via a male, 3-pin or a 5-pin
XLR jack.
10. DMX Out Jack - This jack is used to send an incoming DMX signal to the next fixture
in the DMX chain via a female, 5-pin XLR jack.
11. ESC BUTTON – This button is used to access and exit the fixture’s on-board menu
system.
12. UP BUTTON – This button is used to scroll forward when navigating through the
fixture’s menu system.
13. DOWN BUTTON – This button is used to scroll backwards when navigating through
the fixture’s menu system.
