Design LED 12 Brick II ™
©Elation Professional, Los Angeles Ca. 18 www.ElationLighting.com
8. OPERATING MODES
This fixture can run in three different DMX modes, the following pages will detail the different
operating modes as well as how to achieve the different operating modes.
DMX Settings: The chart below describes how to access the different DMX modes. The
chart below also defines the how the channel will function in the different DMX modes.
1． DMX Mode：
Form 1
DMX
Mode
LED Control model LED
channel
Internal
program
Strobe Dimmer/Speed
15
channel
Each control can be
controlled alone 1~12 13 14 15
12
channel
Each control can be
controlled alone 1~12 N/A N/A N/A
4
channel
Each color can be controlled 1~3 N/A N/A 4
3
channel
Each color can be controlled 1~3 N/A N/A N/A
Specification:
When in 15 channel mode, the reciprocal 3
rd
, is the internal program channel, below the
value:
0---10 No function
11---40 Program 1
41---70 Program 2
71---100 Program 3
101---130 Program 4
131---160 Program 5
161---190 Program 6
191---220 Program 7
221---255 Program 8
When in 15 channel mode, the reciprocal 2
rd
channel is the Strobe channel, below the
value:
0 Open
1----95 Strobe from slow to fast
96----127 Open
128---159 Pulse strobe from slow to fast
160---191 Open
192----223 Random strobe
