Elation Professional LED 12 Brick II User Manual
Page 31
Design LED 12 Brick II ™
©Elation Professional, Los Angeles Ca.
30
www.ElationLighting.com
16.
TECHNICAL SPECIFICATIONS
Power supply:
100V~240V AC, 50Hz~60Hz
Power consumption:
MAX 30w
LED Configuration:
12 1Watt Units (4 x Red, 4x Green 4 x Blue)
Packing
dimensions:
47x26.5x16cm (57x47x36cm ~ 4pc system)
Weight:
3.5Kgs
/
7.72
Lbs
(14Kgs
~
4pc
system
DMX
Channels: 3,
4,
12,
15
DMX
Channel
modes
Drive:
Standard DMX-512, 3 pole XLR; [+] = Pin 3, [-] = Pin 2,
[Ground] = Pin 1 or Standard DMX-512, 5 pole XLR; n/a
= Pin 5, n/a = Pin 4, [+] = Pin 3, [-] = Pin 2, [Ground] =
Pin-
Color Mixing:
RGB Color Additive Mixing
Beam Angle:
44˚
Fuse: GMA
250V~2A
Dimmer:
Continuous Dimming 0~100%
Strobe:
Electronic Strobe 0~18 Fps
Lamp Life:
100,000 Hours Rated Life
Please Note: Specifications and improvements in the design of this unit and this manual are subject to
change without any prior written notice.
