2. Remove and discard the two cardboard
shipping retainers securing the motor
hub in the motor housing assembly.
3. Remove the fan motor assembly from
the protective plastic bag. Place all
carton contents on a protective surface.
J. HANGER
BRACKET
HI
MED
LOW
FAN OFF
EMERSON
D/L
U/L
LIGHT
A. FAN MOTOR ASSEMBLY
C. CEILING COVER
G. LIGHT
PLATE
ASSEMBLY
L. FAN/LIGHT WALL CONTROL
N. LOOSE
PARTS BAG
H. LOWER GLASS
B. COUPLING COVER
D. UPPER DECORATIVE SCROLL
K. 4.5" DOWNROD
M. SW105
RECEIVER
F. FAN
BLADES
E. BLADE
FLANGE
I. HANGER BALL/
8" DOWNROD
ASSEMBLY
NOTE: Place the parts from the loose
parts bags in a small container to keep
them from being lost.
CARDBOARD
SHIPPING
RETAINER (2)
PROTECTIVE
PLASTIC BAG
