Before discarding packaging material, be certain all parts have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION:
The model number of your Fan will be found on a label attached to the top housing.
For repair parts, phone 1-800-654-3545.
• PART NUMBER
• NAME OF ITEM
• PART DESCRIPTION
• MODEL NUMBER
Part Numbers
Key
Model No.
No.
Description
CF750ORB00
*
Hanger Pack, Consisting of:
761655-50
1
Hanger Bracket Assembly (1)
—
2
Hanger Ball (1)
—
3
Downrod, Long 8” (1)
—
*
Parts Bag, Containing:
763304
4
Pin, Clevis (1)
—
5
Clip, Hairpin (1)
—
6
Connector, Wire, 12 Ga. (3)
—
7
Stud, Threaded,
#8-32 x 1-1/4” (2)
—
8
Lockwasher, External Tooth
#8-32 (2)
—
9
Knob, Knurled #8-32 (2)
—
10
Screw, Washer Head,
M5 x 6mm (16)
—
11
Screw, Pan Head,
M5 x 12mm (11)
—
12
Lockwasher, M5 (11)
—
13
Screw, Serrated Head,
M4 x 10mm (4)
—
14
Kit, Balancing (1)
—
15
Cover, Ceiling (1)
763286-ORB
16
Scroll, Decorative Upper (1)
763303-ORB
17
Cover, Coupling (1)
763287-ORB
18
Housing, Assembly, Upper (1)
763288-ORB
19
Glass, Housing Center (1)
763290
20
Harness, Wiring (1)
763302
21
Light Kit Plate Assembly (1)
763307-ORB
22
Glass, Lower (1)
763296
23
Washer, Rubber (1)
763312
24
Jamnut, Hex 1/8-27 NPS (1)
—
25
Nut, Finial (1)
763297-ORB
26
Flange Set
(full set for one fan)
763298-ORB
27
Blade Set
(full set for one fan)
763300
28
Downrod, Short
(4.5”)
761631-37
29
Receiver, SW105 Remote Control (1)
762401
30
Transmitter, Remote Control (1)
763306
—
Owner's Manual (1)
BP7333
Repair Parts Listing
