View Status Options
22
5.3 View Zone Trend
The Zone Trend Log contains up to 288 records that are recorded at
regular intervals (every 24 hours) to assist users with verifying opera-
tional and troubleshooting problems. Records are added the beginning
of the log as they occur.
To view the Zone Trend Log:
• From the Main Menu, use the arrows ↑↓ to choose View Status,
then press Enter ↵.
• From the View Status Menu, use the arrows ↑↓ to choose View
Zone Trend, then press Enter ↵ .
5.3.1 Zone Trend Log
The Zone Trend Log screen displays up to 288 recent readings for each
zone. If the log contains any records, the Zone Trend Log screen dis-
plays details for each zone:
• the name of the zone (for example,
ZONE 1
or
ZONE 2
)
• the value for the amount of current present on each cable (for
example,
0UA
, where UA represents µA or microAmps)
• the date and time of the reading
If there are no records in the log, the screen displays the message:
TREND DATA EMPTY
Viewing Additional Screens
There may be up to 288 records of trend data for each zone.
• To view additional records, use the arrows ↑↓ .
• To return to the previous screen, press the ESC key.
Main Menu
> VIEW STATUS
SYSTEM AND CONTROL
↑↓
=NEXT
↵
=SELECT
View Status Menu
VIEW CABLE STATUS
VIEW ALARM HISTORY
> VIEW ZONE TREND
↑↓
=NEXT
↵
=SELECT
Zone Trend Log
> ZONE TREND 01/288
ZONE 1 0UA
ZONE 2 0UA
29-AUG-03 12:04:00
