View Status Options
19
5.0
V
IEW
S
TATUS
O
PTIONS
The View Status menu allows any user to view the status of cables in both zones, an alarm history log
and a trend log for both zones. The arrows
↑↓
are used to scroll through the menu. The Enter
↵
key is
used to select the menu item.
This section presents step-by-step instructions for each of the following options:
• View Cable Status
• View Alarm History
• View Zone Trend
Figure 15 shows the main options available from the View Status menu.
Figure 15 Menu overview - View Status menu
Opening Screen
LIQUI-TECT PANEL
DD-MON-YY HR:MM:SS
VERSION X.X.X
PRESS
↵
=STATUS/SETUP
Main Menu
> VIEW STATUS
SYSTEM AND CONTROL
↑↓
=NEXT
↵
=SELECT
View Status
VIEW CABLE STATUS
VIEW ALARM HISTORY
VIEW ZONE TREND
↑↓
=NEXT
↵
=SELECT
View Cable Status
STATUS ZN1 ZONE 1
NORMAL
↑↓
=NEXT
See
Section
STATUS ZN1 ZONE 1
LENGTH:
1000FT
CURRENT: 0UA
↑↓
=NEXT
↵
=DONE
STATUS ZN2 ZONE 2
NORMAL
↑↓
=NEXT
STATUS ZN2 ZONE 2
LENGTH:
3500FT
CURRENT: 0UA
↑↓
=NEXT
↵
=DONE
View Zone Trend
> ZONE TREND
288/288
ZONE 1
0 UA
ZONE 2
0 UA
29-AUG-03
12:04:00
See
Section
View Alarm History
> ALARM RECORD 100/100
ZONE 1
CABLE OK
29-AUG-03
12:04:00
See
Section
ZONE 1
ALARM SILENCED - LCD
29-AUG-03
12:00:00
ZONE 1
LEAK @ 2007ft
29-AUG-03
11:48:03
ZONE 1
H/W RESET
29-AUG-03
10:32:22
ZONE 2
CABLE BREAK
29-AUG-03
09:08:07
ZONE 1
LOSS OF POWER
29-AUG-03
07:15:41
View Status options
