SMA Solar Technology AG Technical Data
Installation Guide AS-BOX-XL-IEN094410 47
Feed-in meter connection
Consumption meter connection
Battery Connection
Sunny Backup connection
Nominal current 3 x 160 A
Nominal power 110 kW
Maximum torque 6 Nm … 12 Nm
Maximum cable cross section suitable for connection 70 mm²
Fuse none
Nominal current 3 x 160 A
Nominal power 110 kW
Maximum torque 6 Nm … 12 Nm
Maximum cable cross section suitable for connection 70 mm²
Fuse none
Voltage 48 V
Maximum cable cross section suitable for connection 2.5 mm²
Maximum power consumption at U
Batmin
800 W
Number 6 / 9 / 12
Nominal current 3 x 43.4 A / 3 x 65.1 A / 3 x 86.8 A
Nominal power 30 kW / 45 kW / 60 kW
Maximum cable cross section suitable for connection 16 mm²
Fuses 12 x 32A line circuit breakers
(tripping characteristic C)
