SMA Solar Technology AG

Unpacking

Installation Guide

AS-BOX-XL-IEN094410

13

3.1.2 Multicluster Piggy-Back (optional)

3.2 Identifying the Automatic Switch Box

Identify the Automatic Switch Box by the serial number (Serial No.) and the device type (Type /
Model) on the type label. The type label is on the right side of the enclosure.

Object

Number Description

A

2 - 4

Multicluster Piggy-Back

B

2 - 4

RJ45 cable (5 m, yellow)

C

2 - 4

RJ45 cable (5 m, gray)

D

2 - 4

Grounding cable

E

4 - 8

Termination resistor

F

1

Technical Description
