Epson G3 Series User Manual
Page 44
Setup & Operation 3. Environments and Installation
34
G3 Rev.1
Table Top Mounting
Fitting (black)
for ø4 mm pneumatic tube
Fitting (black) for
ø6 mm pneumatic tube
Fitting (white) for
ø6 mm pneumatic tube
User connector
(15-pin D-sub connector)
Multiple Mounting
Fitting (black) for
ø6 mm pneumatic tube
User connector
(15-pin D-sub connector)
Fitting (white) for
ø6 mm pneumatic tube
Fitting (black) for
ø4 mm pneumatic tube
