SMA Solar Technology AG 9 Technical Data
Installation Manual TCS-IT-IEN103610 33
Dimensions and Weight
Climatic Conditions
Options
9.4 Transformer Compact Station 1000SC
Medium-voltage side
Width x height x depth
with medium-voltage switchgear 3 280 mm x 2 550 mm x 2 500 mm
Width x height x depth
without medium-voltage switchgear 2 380 mm x 2 550 mm x 2 500 mm
Weight with medium-voltage switchgear 15.0 t
Weight without medium-voltage switchgear 10.6 t
Degree of protection
*
*
As per EN 60529
IP23
Operation temperature range − 20°C … +45°C
Relative humidity, non-condensing 15% … 95%
Maximum operating altitude above sea level
(MSL) 1 000 m
Internal power supply transformer
*
* Additional power classes available on request.
6 kVA
Medium-voltage switchgear None / RE-T / C-C-T
Low-voltage switchgear 1 x LV/HRC switch-disconnector /
1 x circuit breaker
Pre-assembled cable set 5 m / 7.5 m / 10 m / 15 m
Communication distribution box Communit
Low-voltage meter GSE meter
Rated power (@ 25°C) P
ACnom
1 100 kVA
AC nominal power (@ 45°C) P
AC
1 000 kVA
AC nominal voltage V
ACnom
15 kV / 20 kV
AC voltage range V
AC
13.5 kV … 16.5 kV / 18 kV … 22 kV
Rated grid voltage V
AC
20 kV
Rated grid frequency f
AC
50 Hz
Nominal current I
nom
28.9 A
