10 Maintenance SMA Solar Technology AG
46 SSMxx-21-IA-BS-JP-en-20 Installation Manual
10.7 Checking the Covers and Labels
Figure 20: Position of the labels in and on the Sunny String-Monitor (with the SSM 21-BS as an example)
Position SMA order number Designation
A 86-101700.02* Risk of electric shock. Do not actuate the load-break switch at temperatures below
-25°C.
B 86-051488 Warning regarding dangerous voltage
C 86-0514 Negative terminal (L − )
D 86-101700.02* Two labels:
Risk of electric shock from active power source
and
Damage to the system due to incorrectly rated fuses Maximum output current:
200 A
or
Risk of electric shock from active power source
and
Damage to the system due to incorrectly rated fuses Maximum output current:
280 A
