Instruction Manual
760004-A
February 2002
Rosemount Analytical Inc. A Division of Emerson Process Management Maintenance and Service 4-21
Model NGA 2000 HFID
Figure 4-18. Flow Controller Assembly
Remove and discard bracket supplied with regulator, assembly as shown.
Sample Sensor
656418
Regulator 250 psi
023382
FLOW
Regulated Air In
Regulated Air Out
Remove red cap
after installation
