Midwest Industries, Inc. Ida Grove, IA 51445 800-859-3028 www.shorelandr.com 0004056
Page 12 of 18 Rev A 08/11/2011
ASSEMBLY & MOUNTING INSTRUCTIONS
JACK - PROFILE 2000 WINCH BASE
The Profile 2000 winch base used on the 2” x 4” and
2” x 5” frame trailers is formed so that the jack can be
mounted directly to it eliminating the need for other
mounting hardware for attaching the jack to the tongue.
The jack required for mounting does not require the
mounting base or any of the original mounting
hardware components.
Assemble as follows:
The jack must be mounted to the winch base before it
is installed on the trailer tongue. If the winch base is
already mounted on the tongue, it will have to be
removed for the jack installation.
Locate the hardware bag and sort all items by size.
Lay the Profile 2000 winch base on its side so the side
that the jack is going to be mounted on is up.
Place the inside jack spacer on the winch base so the
center protrusion fits down into the indent in the winch
base.
Position the jack mounting plate so it is centered
around the inside jack spacer just positioned.
Lay the jack retainer plate on top of the jack mounting
plate aligning the holes in it with the holes in the winch
base.
Insert the two ½” and 1 ¼” carriage bolts into the holes
just aligned in the jack retainer plate and the winch
base. Secure in place with ½” lock washers and hex
nuts. Tighten.
Once tightened, rotate the jack through its normal
pivoting range to make sure it is free to travel and is
not binding up.
If jack pivots, place it on the tongue and secure in
place with the bolts and hardware provided with the
trailer. Complete the assembly of the winch head to the
winch base. Assembly is complete.
