Cable Connection and Rate Selection (Cont’d)
CVC 300 • Rate Selection 4
e
Input Format rotary switch — Use an Extron
Tweeker or other small screwdriver to set the Format
rotary switch to match the video input format. The
following table shows switch settings and their
assigned input video formats.
Position Input Resolutions Output
Position 0 Reserved for future use
Position 1
(Default):
YUVp/HD
480p, 576p, 720p,
1080i, 1080p
RGBHV
Position 2: RGsB
480i/p, 576i/p,
640x480 to 1920x1200
RGBHV
Position 3: YUVi 480i, 576i RGBHV
Position 4: RGsB HD 720p, 1080i, 1080p RGBHV
Position 5: Betacam 50 480i, 576i RGBHV
Position 6: Betacam 60 480i, 576i RGBHV
Position 7: YUVp 480p, 576p RGBS
Position 8 RGsB
480i/p, 576i/p,
640x480 to 1920x1200
RGBS
Position 9: YUVi 480i, 576i RGBS
Position A: RGsB HD 720p, 1080i, 1080p RGBS
Position B: Betacam 50 480i, 576i RGBS
Position C: Betacam 60 480i, 576i RGBS
D, E and F Reserved for future use
Input Format Table (Rotary Switch)
