The Extron CVC 300 Component Video Converter converts all
standard component video formats: NTSC/PAL, DVD, and
Betacam ® , to RGBHV or RGBS; and converts SMPTE HDTV
component video to RGBHV. The CVC 300 can also strip
sync-on-green (SOG) from RGsB video. The converter outputs
RGBHV or RGBS video on BNC connectors. The figure below
shows a typical CVC 300 application.
LAN A C T LINK RESET
7
8
5
6
3
4
1
2 7
8
5
6
3
4
1
2 7
8
5
6
3
4
1
2 7
8
5
6
3
4
1
2 7
8
5
6
3
4
1
2
OUTPU
TS
OUTPUTS
15
16
13
14
11
12
9
10
7
8
5
6
3
4
1
2
15
16
13
14
11
12
9
10
7
8
5
6
3
4
1
2
15
16
13
14
11
12
9
10
7
8
5
6
3
4
1
2
15
16
13
14
11
12
9
10
7
8
5
6
3
4
1
2
15
16
13
14
11
12
9
10
7
8
5
6
3
4
1
2
INPUTS
INPUTS
Matrix Switcher
Projector
RGBHV
Component
PO WE R
12V 3A MA X
CVC 300
OUTPUT R
G
B
V
H/HV
PR/R
PB/ B
Y/G INPU T
DSS Receiver
or
or
Blu-ray Disc
Extron
CVC 300
Component Video
Converter
The component video input formats include SMPTE, HDTV
and Betacam component video. The RGsB video input can be
computer video or NTSC/PAL video.
Mounting
The 1U high, quarter rack width, CVC 300 converter can be
mounted to a rack, under a desk or tabletop, or on a projector
bracket. It can be rack mounted using one-quarter of a 1U
Universal Rack Shelf, RSU 129 (part #60-190-01) or 1U Basic
Rack Shelf, RSB 129 (part #60-604-01).
UL rack mounting guidelines
The following Underwriters Laboratories (UL) guidelines
pertain to the installation of the CVC 300 into a rack.
Elevated operating ambient temperature — If the 1.
equipment is installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the
rack environment may be greater than room ambient
temperature. Therefore, install the converter in an
environment compatible with the maximum ambient
temperature (Tma = +104 °F, +40 °C) specified by Extron.
Introduction
CVC 300 • Installation 1
