80
Technical Details
Physical Specifications
Physical Specifications
CR6400 Router Specifications
CP6464 Control Panel Specifications
Specification Detail
Dimensions Height: 3.47” (88.1mm), fits EIA 2 RU (3.50” or 88.9mm),
Width: 19.0” (482.6mm).
Depth 10.18 ± 0.01” (258.6 mm), enclosure.
< 10.75” (273.1 mm) from front of rack to extended ground screw
Weight 11.8 lb (5.35 kg) with no I/O cards, without control panel.
15.3 lb (6.94 kg) with 4 I/O cards, without control panel.
Connectors Power: 2 connectors. See the drawing under Power Specifications on
page 77.
Ethernet: 1 connector , 10/100BaseT, RJ-45 jack.
Serial: 1 connector, 9-pin D type, usage determined by software, SMPTE
207M.
Video reference: 2 connectors, BNC, 75 W.
Two 2×60 connectors for optional control panel.
Removable module 4 I/O card slots at rear
1 crosspoint card slot at rear
1 control card slot at rear
1 fan module removable at the front
I/O module types SDI. AES
Grounding terminal Copper, accepts 14–6 AWG.
Specification Detail
Dimensions Height: 3.41” (86.6mm),
Width: 17.62” (447.5mm).
Depth 0.50” (12.7mm) enclosure,
0.82” (20.8mm) overall.
Weight 1.43 lb (0.65 kg).
Connectors One 2×60 connector to the CR6400
