Page 37
Kayenne XL Package — Installation and Service Manual
37
Kayak HD 4-RU Video Processor Frame Installation
Kayak HD 4-RU Video Processor Frame Installation
4-RU Frame Dimensions
Figure 13. Kayak HD 4-RU Frame Dimensions
Figure 14. Kayak HD 4-RU Frame Dimensions
177 mm
6.97 in.
482 mm
19.0 in.
465 mm
18.31 in.
165 mm
6.5 in.
Front view
8451_15.1_r1
541 mm
21.29 in.
37 mm
1.43 in.
523 mm
20.58 in.
7.5 mm
0.3 in.
Top view
8451_15.2_r1
442 mm
17.4 in.
Cable Support Wires
