a high-bandwidth cable, such that all the output modules on each frame (up to 6 in total)
have access to all inputs on each frame (up to 192 in total) without any blocking or
bandwidth limitations.
Using Grass Valley’s XEdit software, the two frames can be configured as a single system,
allowing rooms to have a mixture of input modules from either frame. The expansion card
interconnect allows seamless sharing of video, audio monitoring output, time code inputs,
reference input, metadata information (CC, XDS, alarms, etc.), and audio level data. For
more information, refer to the “Kaleido-X (7RU) Expansion” chapter in the Kaleido-X (7RU)
Hardware Description & Installation Manual, available on the DVD that shipped with your
system.
Kaleido-X (14RU) Expansion System Overview
For more information about the Kaleido-X (7RU), refer to the Kaleido-X (7RU) Hardware
Description & Installation Manual.
Getting Organized
This section provides information about system requirements, and items shipped with your
Kaleido-X (7RU).
