GUIDE TO INSTALLATION AND OPERATION
FIO-1901-TT | 17
Copy to other cards
Click this button to open a panel that allows the
alarm configuration set for this card to be copied
into another FIO-1901-TT card.
• Select one or more destination cards from
the list in the window by clicking in the
checkboxes, or all of them by clicking in the
All checkbox
Get alarm keys
Click this button to open a save dialog where you
can save a file containing a list of all alarms on
this card and their current values, along with an
Alarm Key for each. The alarm keys are useful for
system integration and troubleshooting.
• The file is saved in .csv format
OK, Apply, Cancel
• OK accepts the settings and closes the window once the card confirms that there are no errors.
• Apply accepts the settings, but leaves the window open
• Cancel closes the window without applying any changes, and leaves the previous settings intact.
Figure 3.12 Save dialog for Get Alarm Keys
Figure 3.11 Copy to Other Cards
