Grass Valley Acappella v.3.1.0 User Manual
Page 25
Acappella — Instruction Manual
25
Hardware Description
The configuration shown in
is 8 Inputs by 4 Outputs of dual
stream digital (AES) audio.
Figure 23. 8x4 Audio Dual Stream BNC Backplane
8300_00_33
The empty configuration shown in
is used on systems that have
video with no audio.
Figure 24. Empty Audio Backplane
8300_00_36
