LDK 5309/10 9-inch LCD HD color viewfinder User’s Guide (v1.0) 35
Chapter 4 - Viewfinder setup menu
4.1.4 Indicator adjustment
4.1.5 Focus (“Focus”)
Control Item Value(s) Description
Menu EXIT INDADJ Exits the indicator adjustment menu. Set
indicator levels are stored in memory.
Button1 IndLvl {Low, Med,
High} Selects the indicator level for the ISO, On-Air
and Call indicators.
Button2 — — —
Button3 — — —
Rotary1 ISO 0..99 (99) Adjusts the intensity of the selected indicator
(Low, Med or High) level for the ISO (yellow)
indicators (both left and right).
Rotary2 OnAir 0..99 (99) Adjusts the intensity of the selected indicator
(Low, Med or High) level for the OnAir (red)
indicators (both left and right).
Rotary3 Call 0..99 (99) Adjusts the intensity of the selected indicator
(Low, Med or High) level for the Call (green)
indicators (both left and right).
Control Item Value(s) Description
Menu EXIT FOCUS Exits the focus menu.
Button1 Bar {Off, Top, Right,
Bttm, Left} Selects the screen position of the focus bar.
Button2 Area {Centre, All,
Zoom} Focus measurement window:

centre = center-weighted average; All = full
screen average; Zoom = follow zoom area
Button3 — —
Rotary1 Gain 0..99 (50) Sets sensitivity of focus bar range
Rotary2 P/Hold 0..99 (50) Sets peak/hold time (0 = 0 video frames, 99 =
255 frames)
Rotary3 PREV
↑
NEXT
↓
Selects a menu from the list.
