28 LDK 5309/10 9-inch LCD HD color viewfinder User’s Guide (v1.0)
Chapter 3 - Operation
3.2 Operational functions
Many operational functions can be assigned to the user buttons at the bottom of the
viewfinder. Refer to
“Button assignment menu” on page 31 to read more about
assigning user buttons.
3.2.1 Box
Turns the framing box on or off. This superimposed box is a very useful feature to
help focussing and framing while shooting. Three box types are available:
The framing box can be selected and set up in the viewfinder setup menu. Refer to
“Box setup (“Box”)” on page 37 for more information.
3.2.2 Monochrome
Switches the viewfinder to monochrome mode. Select the source (Y, R, G, B or -G)
in the viewfinder setup menu. When the camera color bar is switched on, the
viewfinder returns to color mode.
3.2.3 Ext1
Press the button to show the external (return) video channel 1.
3.2.4 Ext2
Press the button to show the external (return) video channel 2.
box type line type full type
