8
• IP ToS—ToS of IP.
• IP DSCP—DSCP of IP.
• TCP flag—Some bits in the six flag bits (URG, ACK, PSH, RST, SYN, and FIN) are concerned.
• IP fragment—Whether the packet is an IP packet fragment.
• Rate limit
You can use the collaboration policy to manage the collaboration rules that belong to it.
ACFP usage guidelines
• In a GRE tunneling environment, an ACFP policy can be configured on a tunnel interface only.
• ACFP does not support policy-based routing services or NetStream services.
• The handling of the packets that are redirected by ACFP and the part of the QoS processing (FR-DE
matching, ATM-CLP matching, inbound interface matching, QoS local-id, local precedence, and so
on) are mutually exclusive. No QoS processing is performed on the packets returned after they are
redirected to the ACFP client.
• On the destination interface, packets redirected or mirrored by ACFP support only Layer 2 QoS
processing, including queuing and WRED. They do not support any other service processing, such
as non-Layer 2 QoS processing and non-QoS service processing.
• With ACFP, a stream cannot be mirrored or redirected to multiple ACFP clients.
• ACFP cannot process outbound packets.
ACFP configuration task list
Task Remarks
Enabling the ACFP server on the device Required.
Configuring the ACFP client (the OAP module) Required.
Enabling the ACFP trap function on the device Optional.
Enabling the ACFP server on the device
Step Command Remarks
1. Enter system view. system-view N/A
2. Enable the ACFP server. acfp server enable Disabled by default.
Configuring the ACFP client (the OAP module)
You can use a MIB browser to configure ACFP collaboration policies and ACFP collaboration rules. The
configuration procedure depends on the software used on the ACFP client.
